Epic Vision Horizontal Floor Model System - Fixed Lens Video Comparator - 3 Axis CNC with M3 Software
Reference: EVHF-FIXED-M3-CNC3
$65,550.00
The J&L Epic Vision EVHF Fixed-M3-CNC3 Horizontal Floor Model Video Comparator with M3 Edge Detection Software
M3 High-Resolution 5MP Digital Camera: Offering fixed or zoom magnification with a Superb Image. The camera provides exceptional clarity for detailed inspections and precise analysis. This range is ideal for both low- and high-magnification tasks in engineering and quality control.
Metlogix M3 Software Integration: The system is equipped with the Metlogix M3 software, which supports seamless measurement workflows. Its advanced edge detection and geometric measurement capabilities, combined with a user-friendly touch interface, make it highly efficient for complex measurements. Engineers can also leverage Part Programs for automatic measurement routines for repeatable tasks.
Motorized CNC 3 Axis Stage for Fast Automatic Measurements -The CNC 3 -Axis Stage enhances the efficiency of measurement workflows by allowing fast automatic measurements. With this feature, engineers can measure a part once, store the measurement program, and then run the same process on multiple parts automatically. The system compares each part's measurements to nominals and tolerances, ensuring consistency and accuracy across batches.
Powerful On-Screen and Stage-Based Measurement Tools: The system includes integrated software and hardware for accurate on-screen measurements, combined with stage-based movement controls for precise object positioning. and measurement
Robust Construction: The system boasts a stable cast iron work surface, ensuring durability and stability for accurate measurements and inspections, even in demanding environments.
Large Measurement Motorized Envelope: With a 12" x 10" x 2.5" measurement envelope, the EVHF accommodates a wide variety of parts and components, enhancing its versatility for numerous applications. X axis is upgradeable to 16" and can be CNC controlled for automated measurements.
Heavy Weight Capacity - 500 lbs Standard with Upgrades to 12000 lbs or Extreme Capacity of 2800 lbs
High Magnification and Wide Field of View: Designed for the shop floor environment, this system offers a combination of high magnification and a wide field of view, enabling detailed close-up inspections essential for applications that demand both precision and accuracy.
High-Intensity LED Integrated Lighting: The system incorporates integrated high-intensity LED lighting controls, eliminating the need for traditional bulbs. This feature ensures consistent illumination across all working conditions, enhancing visibility without glare or shadows.
Engineers will find the J&L EVHB-FIXED-M3-CNC3 System to be a powerful and versatile tool for high-precision measurements, making it a critical asset in manufacturing, R&D, and quality control environments.
Epic Vision EVHF-Fixed-M3-CNC3 , Floor Model Horizontal Video Comparator with M3 Advanced Edge Detection Software
It's a Comparator. It's a Video Measurement System. It's a 4K Inspection Microscope - All in One!
Experience Unmatched Clarity and Precision with the J&L EVHF Horizontal Video Comparator
The Metlogix M3 Software brings advanced edge detection, part programming, and comprehensive report generation to the world of Optical and Video Comparators. With integrated LED lighting, this system ensures optimal visibility, while the image capture feature allows you to document every intricate detail effortlessly. What truly sets the J&L EVHF apart is the seamless integration of on-screen measurement tools.
This workstation features a robust 16" x 10" Steel Stage with superb full-color optics, offering both on-screen and stage-based measurement capabilities, all with the ease of image capture. Elevate your work with unparalleled technology and convenience. Invest in accuracy, invest in the J&L EVHF Horizontal Video Comparator -- the perfect blend of precision and affordability for your measurement needs.
Superb 4K Smart Cam Image: A 4K camera system providing high-resolution images with the capability for image capture and annotation, useful for detailed inspection and reporting.Seamless Image Capture: Effortlessly document images for reports or presentations, streamlining workflows and improving efficiency.
Seamless Image Capture: Effortlessly document images for reports or presentations, streamlining workflows and improving efficiency.
Powerful On-Screen and Stage-Based Measurement Tools: Integrated software or hardware provides accurate on-screen measurements, while stage-based controls ensure precise object positioning for complex measurement tasks.
High Magnification and Wide Field of View: Designed for the shop floor environment, this system offers a combination of high magnification and a wide field of view, enabling detailed close-up inspections essential for applications that demand both precision and accuracy.
Robust Construction: Built with a stable cast iron work surface, ensuring durability and stability for accurate measurements, even in the most demanding environments.
Large Measurement Motorized Envelope: With a 12" x 10" x 2.5" measurement envelope, the EVHF accommodates a wide variety of parts and components, enhancing its versatility for numerous applications. X axis is upgradeable to 16" and can be CNC controlled for automated measurements.
Heavy Weight Capacity - 500 lbs Standard with Upgrades to 12000 lbs or Extreme Capacity of 2800 lbs
Integrated LED Lighting: High-intensity, adjustable LED lighting eliminates shadows and glare, providing consistent illumination to maintain precise measurement conditions.Metlogix M3 Software Integration: The system is equipped with the Metlogix M3 software, which supports seamless measurement workflows. Its advanced edge detection and geometric measurement capabilities, combined with a user-friendly touch interface, make it highly efficient for complex measurements. Engineers can also leverage Part Programs for automatic measurement routines for repeatable tasks.
Motorized CNC 3 Axis Stage for Fast Automatic Measurements -The CNC 3-Axis Stage enhances the efficiency of measurement workflows by allowing fast automatic measurements. With this feature, engineers can measure a part once, store the measurement program, and then run the same process on multiple parts automatically. The system compares each part's measurements to nominals and tolerances, ensuring consistency and accuracy across batches. Built in the USA with Robust Warranties:
